A couple of motherboards recently landed in the lab that filled a large void in the marketplace. Just after the introduction of Intel's new Core 2 Duo and Extreme processors with 1333MHz front side bus frequencies, if you wanted a motherboard that officially supported one of the new CPUs, that also had a balanced (and flexible) PCI Express lane configuration for better multi-GPU CrossFire support, you were basically up a creek. NVIDIA's nForce 680i SLI chipset supported the new processors, but we all know there is a large contingent of enthusiasts who prefer using Intel processors with Intel chipsets. Them's the breaks. Unfortunately, the P35 chipset was the only game in town with true 1333MHz FSB and CrossFire support, and like the P965 that came before it, its PCI Express lane configuration was unbalanced. With the P35, the first PEG slot got a full 16 lanes of PCI Express connectivity, while the second slot got only 4. In addition, those 4 lanes powering the second slot were connected to the Southbridge, which then in turn has to interface with the Northbridge over another link, adding latency to the equation. This setup works fine for single-GPU configurations, and admittedly works fine for CrossFire, but it doesn't offer optimal performance.
Asus saw the need for an enthusiast-class motherboard based on the P35 chipset, but with a more flexible PCI Express configuration. And leveraging what they undoubtedly learned from designing the PW564-WS , engineered the Blitz Extreme and Blitz Formula motherboards, complete with a PCI Express switch that allowed them to connect the P35 Northbridge's PCI Express lanes to a pair of PEG slots. Asus didn't stop there, however, and also outfitted the Blitz boards with a hybrid air / liquid cooling apparatus and a number of other features that are sure to please.
CPU
LGA775 socket for Intel Core 2 Extreme / Core 2 Quad / Core 2 Duo / Pentium Extreme / Pentium D / Pentium 4 / Celeron D Processors
Support Intel next gen 45nm Multi-Core CPU
Compatible with Intel 06/05B/05A processors
Chipset
Intel P35/ICH9R with Intel Fast Memory Access Technology
Front Side Bus 1333 / 1066 / 800 MHz
Memory (Blitz Extreme)
Dual channel memory architecture
4 x DIMM, max. 8GB, DDR3-1333*/1066/800, non-ECC and un-buffered memory
The chipset officially supports the memory frequency up to DDR3 1066MHz/DDR2 800. Due to the tuning by ASUS exclusive technology, this motherboard natively supports up to DDR3 1333/DDR2 1066MHz. Please refer to www.asus.com or user manual for Memory QVL
Memory (Blitz Formula)
Dual channel memory architecture
4 x DIMM, max. 8GB, DDR2-1066*/800/667 MHz, non-ECC and un-buffered memory
The chipset officially supports the memory frequency up to DDR2 800 MHz. Due to the tuning by ASUS exclusive technology, this motherboard natively supports up to DDR2 1066MHz. Please refer to www.asus.com or user manual for Memory QVL
Expansion Slots
2 x PCI Express x16 slot, support dual graphics solution
3 x PCI Express x1, PCIex1_1 (black) is compatible with audio slot
2 x PCI 2.2
CrossFire
Support ATI CrossFire graphics cards (both at x8 mode)
Storage
Southbridge
6 x SATA 3.0 Gb/s ports
Intel Matrix Storage Technology supports RAID 0, 1, 5 and 10.
JMicron JMB363 PATA and SATA controller
1 x UltraDMA 133/100/66 for up to 2 PATA devices
2 x External SATA 3.0 Gb/s port (SATA On-the-Go)
LAN
Dual Gigabit LAN controllers, with AI NET2
High Definition Audio
SupremeFX II Audio Card
ADI 1988B 8-channel High Definition Audio CODEC
Noise Filter
Coaxial, Optical S/PDIF out at back I/O
IEEE 1394a
2 x 1394a ports (1 x back I/O, 1 x onboard)
USB
Max. 12 USB2.0/1.1 ports(6 ports at mid-board, 6 ports at back panel)
BIOS
16Mb AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.4, ACPI2.0a Multi-Language BIOS
Overclocking Features
Crosslinx Technology
Extreme Tweaker
Loadline Calibration
Intelligent overclocking tools:
CPU level Up
AI NOS (Non-delay Overclocking System)
AI Overclocking (intelligent CPU frequency tuner)
ASUS AI Booster Utility
O.C Profile
Overclocking Protection:
COP EX (Component Overheat Protection - EX)
Voltiminder LED
ASUS C.P.R.(CPU Parameter Recall)
Special Features
Fusion Block System
LCD Poster
EL I/O
Onboard Switches: Power / Reset
Q-Connector
Q-Fan Plus
ASUS EZ Flash2 / CrashFree BIOS3
ASUS MyLogo3
Back Panel I/O Ports
1 x PS/2 Keyboard port(purple)
1 x Optical + 1 x Coaxial S/PDIF Output
2 x External SATA
2 x LAN (RJ45) port
6 x USB 2.0/1.1 ports
1 x IEEE1394a port
1 x Clr CMOS switch
Internal I/O Connectors
3 x USB 2.0 connectors supports additional 6 USB 2.0 ports
1 x Floppy disk drive connector
1 x IDE connector for two devices
6 x SATA connectors
8 x Fan connectors: 1 x CPU / 1 x PWR / 4 x Chassis / 2 x Optional
2 x thermal sensor connectors
1 x IEEE1394a connector
1 x S/PDIF output connector
1 x Chassis Intrusion connector
24-pin ATX Power connector
8-pin ATX 12V Power connector
1 x En/Dis-able Clr CMOS
1 x EL I/O Shield Connector
Manageability
WOL by PME, WOR by PME, Chasis Intrusion, PXE
Accessories
Fusion Block System Accessory
DIY Pedestal
ASUS Optional Fan
3 in 1 ASUS Q-Connector Kit
UltraDMA 133/100/66 cable
Floppy disk drive cable
SATA data and power cables
2-port USB2.0 module
IEEE1394a module
EL I/O Shield
Thermal sensor cables
Cable Ties
User's manual
Software
The hottest 3D Game: S.T.A.L.K.E.R.
Support DVD:
Drivers
ASUS PC Probe II
ASUS Update
ASUS AI Suite
Futuremark 3DMark06 Advanced Edition
Kaspersky Anti-Virus
Form Factor
ATX Form Factor, 12"x 9.6" (30.5cm x 24.5cm)
